23 Watt T5 LED; 4000K; 120-277 Volt; Miniature Bi Pin base; Type C; External Driver required (LNK2F)
23 Watt T5 LED; 4000K; 120-277 Volt; Miniature Bi Pin base; Type C; External Driver required
Product Specification
Item #
LNK2F
Dimensions
Width: 0.63"
Additional product details
Category
Light Bulbs
Subcategory
LED Bulbs
Finish
White
Style
Traditional
Lumens
3300+
Kelvin
3501-4000
Category
LED
Sub-Category
LED T5
Volts
120V-277V
Bulb Dimmable
Yes-Dimmable
Bulb Hours
50000
Bulb Kelvin
4000K
Bulb Shape
T5
Diameter
0.63
EA Length
45.7
Harmonized Codes
8539.52.0051
Length
48
Lumens
3400L
Shap Carton Width
0.62
Ship Carton Height
0.62
Ship Weight
0.31
Warranty
5 Year Limited - LED Type C Bulbs
Weight
0.31
AC/DC
120-277VAC 43VDC 290mA
Additional Info
Not for emergency lighting
BAA Compliant
No
Ballast Bypass Direct
Replace with external driver
Ballasting Requirements
Ballast replaced with external driver
Beam Spread
220
Bulb ANSI Base
G5
Bulb Base
Miniature Bi Pin
Bulb Finish
Frost
Burning Position
Universal
Carton Cubic Feet
0.0102
Cartons Per Unit
1
CCT Selectable
No
CEC
Exempt - Base Not Regulated
CEC Terse
Lawful for sale in California
CEC Web Text
Lawful for sale
Color Temprature
Cool White
Country Of Origin
China
CRI
82
Dimmable Down To
100 to 20 percent
Dimmable Function
0-10V Dimming Only
DLC Approved
Yes
DLC Classification
Standard
DLC ID
PLCXVV6NDZC1
DLC Primary Use
4-lamp External Driver (UL Type C) Lamps
Efficacy
147.83 LPW
Enclosed Fixture Use
Yes
Enclosure Rating
Enclosed Rated Lamp
FCC Compliant
Yes
Feature 1
Cool white light
Feature 2
Damp rated for indoor use
Feature 3
Enclosed Rated Lamp
Feature 4
L:48.00 D:0.63
Feature 5
T8, Frosted Finish
Flourescent Equivalent
54W
Incandescent Equivalent
100W
Installation Notes
Not for use in vapor tight fixtures.
JA8 Compliant
No
Lamp Ballast Type A/B/C
Type C
Lamp Filament
LED
Lens
Yes
Lens Finish
Frost
Location Rating
Damp
Long Description
SATCO|NUVO's S11943 23-watt LED, T5 bulb is an ideal lighting solution for a variety of applications. This easy to install, low maintenance lamp has a 220-degree beam spread and high lumens count for superior illumination. Dimmable and versatile, this
Material
Glass
Nominal Length
48
NSF Approved
ETL Sanitation listed (conforms to NSF)
Operating Frequency
50/60Hz
Operating Temp
-20C (-4F) to +45C (+113F)
Order In Multiples Of
25
Pack Type
Sleeve
Power Factor
0.9
Quantity In Pack
1
R9 Value
7
RoHS Compliant
Yes
Romance Copy
SATCO|NUVO's 23-watt LED, T5 bulb is an ideal lighting solution for a variety of applications. This easy to install, low maintenance lamp has a 220-degree beam spread and high lumens count for superior illumination. Dimmable and versatile, this lamp de
SDS class
LED_Lamp
Short Description
23T5/LED/48-840/XD
Style
Utility
Technology
LED
Title 20 Compliant
No
Title 24 Compliant
No
Total Harmonic Distortion
20%
Wattage Selectable
No
Watts
23W
Finish Family
